The 2022 Tesla Model X Plaid was an SUV produced from 2022 to 2024. It features a tri motor (permanent magnet, carbon-sleeved rotors) AWD powertrain. EPA-rated range is 333 miles with 98 MPGe. It accelerates from 0 to 60 mph in 2.5 seconds. Top speed is 163 mph. Manufactured at Fremont, CA.
The Plaid Model X took Tesla's tri-motor powertrain from the Model S Plaid and stuffed it into a three-row SUV with falcon wing doors. The result was the fastest-accelerating SUV ever produced, capable of sub-2.5-second 0-60 times. It hit quarter-mile numbers that would've won street races a decade earlier.
Unlike previous performance Model X trims that used two motors, the Plaid added a carbon-sleeved rear motor spinning at higher RPMs for more top-end power. It shared the refreshed Palladium interior with its Long Range sibling, including the yoke and the rear entertainment screen. The Plaid X occupied a strange and wonderful niche: a family hauler with hypercar acceleration.
- Tri-motor Plaid powertrain: 1,020 HP, 2.5s 0-60 mph (with rollout)
- 163 mph top speed (highest of any SUV in production)
- 6-piston front brakes; 25.6" wheels available on Track Mode
- AMD Ryzen MCU and rear-seat gaming display
| 20" Cyberstream | 333 mi |
| 22" Turbine | 311 mi |
| Peak DC Fast | 250 kW |
| DC Fast 10-80% | ~28 min |
| AC Onboard Charger | 11.5 kW |
| Home L2 (full charge) | ~8.7 hrs |
| Connector | Tesla (NACS adapter) |
| Model Years | 2022–2024 |
| Model | Tesla Model X |
| Variant | Plaid |
| Status | Discontinued |
| Generation | Model X (Palladium) |
| Body Type | SUV |
| Seats | 7 |
| Doors | 4 |
| Drivetrain | AWD |
| Motor(s) | Tri Motor (Permanent Magnet, carbon-sleeved rotors) |
| Battery Capacity | 100 kWh |
| EPA Range | 333 miles |
| MPGe | 98 |
| Efficiency | 34 kWh/100mi |
| 0-60 mph | 2.5 sec |
| Top Speed | 163 mph |
| Horsepower (est.) | 1,020 HP |
| Curb Weight | 5,390 lbs |
| Cargo Volume | 91 cu ft |
| Length | 198.3" |
| Width | 78.7" |
| Height | 66.3" |
| Wheelbase | 116.7" |
| Production Start | 2022-03 |
| Production End | 2024-12 |
| Autopilot | Autopilot standard, FSD optional |
| Factory | Fremont, CA |
| Basic Vehicle Warranty | 4 years / 50,000 miles |
| Battery & Drive Unit | 8 years / 150,000 miles |
- Tri-motor
- 1,020 HP
- Fastest SUV in production
- Falcon wing doors
